SD42940 $SC_TOOL_LENGTH_CONST Change of tool length components at change of
plane
= 17 L1 = Z, L2 = Y, L3 = X
SD42942 $SC_TOOL_LENGTH_CONST_T Change of tool length components for turning tools
at change of plane
= 19 L1 = Z, L2 = Y, L3 = X
Note
SD42942 is only evaluated after setting SD42950.
SD42950 $SC_TOOL_LENGTH_TYPE Assignment of the tool length offset independent
of tool type
= 3 The assignment of the tool length components is performed separately for the turning and
grinding tools (tool types 400 to 599) on the one hand and all other tools (milling tools)
on the other hand.
SD42954 $SC_TOOL_ORI_CONST_M Change of tool orientation components for milling
tools at change of plane
= 0 Orientation for milling tools: Standard
SD42956 $SC_TOOL_ORI_CONST_T Change of tool orientation components for turning
tools at change of plane
= 18 Orientation for turning tools: G18
SD42998 $SC_CUTMOD_PLANE_TOL Difference between tool tip plane and machining
plane
= 5 Maximum permissible difference for gamma of 0° to 180°
SD42999 $SC_ORISOLH_INCLINE_TOL Difference between tool tip plane and machining
plane for ORISOLH
= 1 Maximum permissible inclination of the tool tip compared to the G18 plane for "Align tool
directly"
In the following setting data, index [k] stands for the number of the current data field (probe
number -1) of the probe.
SD54633 $SNS_MEA_TP_TYPE[k] Probe type, cube/disk
= 0 Compatibility (measuring cycles: cube, turning surface shows probe, milling surface
shows disk)
= 3 Cube
Technologies and cycles
21.8 Turning on milling machines
SINUMERIK Operate (IM9)
602 Commissioning Manual, 12/2017, 6FC5397-1DP40-6BA1
