Workpiece measurement
For milling:
● The probe has been inserted in the tool spindle.
● The probe has been selected in the tool list as type 7xx (probe).
● The probe is activated as tool in the current NC channel.
Tool measurement
To measure tools, an appropriate probe must be located in the machine space so that this can
be reliably and safely reached with a tool in the spindle.
The following tool types are supported with measure tool:
● Milling technology: Tool types 1xx and 2xx
● Turning technology: Tool types 5xx, 1xx and 2xx
For the specified tool types, the tool lengths and the tool radii can be measured.
Setting general data
SD54782 $SNS_J_MEA_FUNCTION_MASK_TOOL Settings for the input screen, measuring
in JOG, tool measurement.
Bit 2 = 1 Activates the "Enable automatic tool measuring" function.
Bit 3 = 1 Selects the tool probe calibration data field, enable.
Bit 10 = 1 Selects the individual cutting edge measurement
Bit 11 = 1 Selects the spindle reversal when calibrating in the plane
MD51784 $MNS_J_MEA_T_PROBE_APPR_AX_DIR [i]
Measuring in JOG: Approach direction in the plane to the tool probe
-2 Negative direction, 2nd measuring axis
-1 Negative direction, 1st measuring axis (default setting)
0
Positive direction, 1st measuring axis
1
2 Positive direction, 2nd measuring axis
MD52750 $MCS_J_MEA_FIXPOINT Z value for measurement with respect to
a fixed point
MD52751 $MCS_J_MEA_MAGN_GLAS_POS Zoom-in position for tool measurement
[0] Position in the 1st axis
[1] Position in the 2nd axis
Technologies and cycles
21.10 Measuring cycles and measurement functions
SINUMERIK Operate (IM9)
624 Commissioning Manual, 12/2017, 6FC5397-1DP40-6BA1
