Checking and setting the general machine data
MD11450 $MN_SEARCH_RUN_MODE "Search run" programming.
Bit 1 = 1 Automatic ASUB start after output of the action blocks (see also
MD11620 $MN_PROG_EVENT_NAME). Alarm 10208 is not output until the ASUB is
completed.
MD11604 $MN_ASUP_START_PRIO_LEVEL Priorities from which ASUP_START_MASK is
effective.
= 1 - 64 Priorities for ASUP_START_MASK.
Setting channel-specific machine data
MD20050 $MC_AXCONF_GEOAX_ASIGN_TAB[ ] Assignment, geometry axis to channel axis.
[0] For measuring in JOG mode, all of the geometry axes must be available. Preferably XYZ.
[1]
[2]
MD20110 $MC_RESET_MODE_MASK Defines the basic control settings after reset /
TP end,
= 4045H Minimum value
Bit 0 = 1 Basic control setting after power on and reset.
Bit 2 = 1
Bit 6 = 1
Bit 14 = 1
MD20112 $MC_START_MODE_MASK Definition of the basic control setting after part
program start.
= 400H Minimum value
Bit 6 = 0 Definition of the basic control setting after NC start.
MD20310 $MC_TOOL_MANAGEMENT_MASK Activates tool manager functions
= 4002H Minimum value
Bit 1 = 1 Tool manager and monitoring functions active
Bit 14 = 1 Automatic tool change for RESET and Start.
MD28082 $MC_SYSTEM_FRAME_MASK System frames (SRAM).
Bit 0 = 0 Do not setup system frames for actual value setting and scratching.
Bit 0 = 1 Setup system frames for actual value setting and scratching.
Technologies and cycles
21.10 Measuring cycles and measurement functions
SINUMERIK Operate (IM9)
Commissioning Manual, 12/2017, 6FC5397-1DP40-6BA1 625
