Tag identifier Meaning
RECALL This tag can be used in a menu if a navigation is to take place via Recall button. If the tag is
programmed, the Recall icon is shown, and the parser may process the Recall button.
Syntax:
<recall>
…
…
</recall>
UPDATE_CONTROLS The tag runs a comparison between the operator controls and the reference variables.
Attribute:
● type
The attribute defines the direction of the data comparison.
= TRUE – data is read from the reference variables and copied to the operator controls.
= FALSE – Data is copied from the operator controls to the reference variables.
Syntax:
<UPDATE_CONTROLS type = "<Direction>"/>
Example:
<SOFTKEY_OK>
< UPDATE_CONTROLS type="false"/>
</SOFTKEY_OK>
Generating user dialogs
1.7 XML identifier
Easy XML
80 Programming Manual, 12/2017, 6FC5397-1DP40-6BA1
