Control variable Meaning/behavior
backgroundpicturedisabled_keepaspectratio Variable type: Bool
Value:
1 = true
0 = false
The aspect ratio of the "disabled state" back‐
ground icon is retained or ignored
backgroundpicturepressed_keepaspectratio Variable type: Bool
Value:
1 = true
0 = false
The aspect ratio of the "pressed state" background
icon is retained or ignored
picture_keepaspectratio Variable type: Bool
Value:
1 = true
0 = false
The aspect ratio of the icon is retained or ignored
picturedisabled_keepaspectratio Variable type: Bool
Value:
1 = true
0 = false
The aspect ratio of the "disabled state" icon is re‐
tained or ignored
picturepressed_keepaspectratio Variable type: Bool
Value:
1 = true
0 = false
The aspect ratio of the "pressed state" icon is re‐
tained or ignored
backgroundpicture_scaled Variable type: Bool
Value:
1 = true
0 = false
The background icon is adjusted to the dimensions
of the button
backgroundpicturedisabled_scaled Variable type: Bool
Value:
1 = true
0 = false
The "disabled state" background icon is adjusted
to the dimensions of the button
Generating user dialogs
1.12 Configuring your own buttons
Easy XML
154 Programming Manual, 12/2017, 6FC5397-1DP40-6BA1
