Control variable Meaning/behavior
backgroundpicturepressed_scaled Variable type: Bool
Value:
1 = true
0 = false
The "pressed state" background icon is adjusted
to the dimensions of the button
picture_scaled Variable type: Bool
Value:
1 = true
0 = false
The icon is adjusted to the dimensions of the button
picturedisabled_scaled Variable type: Bool
Value:
1 = true
0 = false
The "disabled state" icon is adjusted to the dimen‐
sions of the button
picturepressed_scaled Variable type: Bool
The "pressed state" icon is adjusted to the dimen‐
sions of the button
backpicture_alignment Variable type: String
See attribute alignment
backgroundpicturedisabled_alignment
backgroundpicturepressed_alignment
picture_alignment
picturedisabled_alignment
picturepressed_alignment
caption Variable type: String
"Not pressed state" button text
captionpressed Variable type: String
"Pressed state" button text
caption_alignment Variable type: String
See attribute alignment
captionpressed_alignment
captiondisabled_alignment
disabled Variable type: Bool
Value:
1 = true - pushbutton disabled
0 = false - pushbutton can be operated
Generating user dialogs
1.12 Configuring your own buttons
Easy XML
Programming Manual, 12/2017, 6FC5397-1DP40-6BA1 155
