example, as seen by the consumer) as positive. With the P, Q sign parameter, you can invert the sign for
these components. This inversion does not influence any protection function.
Write-Protected Settings
The settings listed here are used primarily for understanding during configuration of the function groups. They
are calculated on the basis of other settings and cannot be directly changed.
Addr. Parameter C Setting Options Default Setting
Rated values
_:9421:103 General:Rated apparent
power
-1.00 MVA to -1.00 MVA 0.00 MVA
Power-system data
_:9421:214 General:M I-1ph uses
MeasP with ID
0 to 100 0
_:9421:223 General:CT mismatch M
I-1ph
0.00 to 100.00 0.00
Settings
Addr. Parameter C Setting Options Default Setting
Rated values
_:9421:101 General:Rated current 1 A to 100 000 A 1000 A
_:9421:102 General:Rated voltage 0.20 kV to 1200.00 kV 400.00 kV
Measurements
_:9421:150 General:P, Q sign
•
not reversed
•
reversed
not reversed
Information List
No.
Information Data Class
(Type)
Type
General
_:9421:52 General:Behavior ENS O
_:9421:53 General:Health ENS O
Group indicat.
_:4501:55 Group indicat.:Pickup ACD O
_:4501:57 Group indicat.:Operate ACT O
Reset LED Group
_:13381:500 Reset LED Group:>LED reset SPS I
_:13381:320 Reset LED Group:LED have been reset SPS O
6.2.4
6.2.5
6.2.6
Function-Group Types
6.2 Function-Group Type Voltage/current 1-Phase
144 SIPROTEC 5, Fault Recorder, Manual
C53000-G5040-C018-5, Edition 11.2017

Siemens SIPROTEC 5 Specifications

General

Series	SIPROTEC 5
Communication Protocols	IEC 61850, DNP3, Modbus
Cybersecurity	Role-based access control, secure communication
Modular Design	Yes
Hardware Redundancy	Optional
Operating Temperature	-25°C to +70°C
Digital Inputs	Configurable, number depends on I/O modules
Digital Outputs	Configurable, number depends on I/O modules
Analog Inputs	Configurable, number depends on I/O modules
Current Transformer Inputs	Configurable, number depends on I/O modules
Voltage Transformer Inputs	Configurable, number depends on I/O modules
Time Synchronization	IRIG-B, SNTP, PTP
Protection Functions	Overcurrent, Differential, Distance, Over/Under Voltage, Frequency
Housing	19-inch Rack Mount
Dimensions	Depends on module configuration
Weight	Depends on module configuration
Voltage Input	24V DC, 48V DC, 110V DC, 125V DC, 220V DC, 250V DC
