Addr. Parameter C Setting Options Default Setting
_:10111:112 Continuous 1:Averaging
time
•
1 s
•
2 s
•
5 s
•
10 s
•
30 s
•
60 s
•
120 s
•
150 s
•
300 s
•
600 s
•
900 s
600 s
Information List
No. Information Data Class
(Type)
Type
Binary IO
_:2731:51 General:Mode (controllable) ENC C
_:2731:52 General:Behavior ENS O
_:2731:53 General:Health ENS O
Binary IO
_:10111:322 Continuous 1:Recorder formatted SPS O
Trend Recorder
Overview of Functions
Trend recorders are used for long-term recording and monitoring the process of voltage change within toler-
ance ranges that can be set using parameters. The flicker measurement can also be determined and stored in
the trend recorder.
Structure of the Function
The Trend recorder function is not preconfigured at the factory. Within the Recorder function group, the
Trend recorder can be operated a maximum of 2 times.
[dwtrend7k-160514-01.vsd, 1, en_US]
Figure 7-31 Structure/Embedding of the Function
Function Description
The trend recorder ensures capture and long-term supervision of frequency and voltage when the voltage and
frequency change. If a change occurs in the measurand with respect to the last captured RMS value during the
parameterized measuring interval, and this change exceeds the set tolerance range, the new RMS value is
recorded.
7.2.8.6
7.2.9
7.2.9.1
7.2.9.2
7.2.9.3
Fault Recorder
7.2 Function-Group Type Recorder
250 SIPROTEC 5, Fault Recorder, Manual
C53000-G5040-C018-5, Edition 11.2017
