Siemens SIPROTEC 5 User Manual

Information List
General
No. Information Data Class
(Type)
Type
General
_:2311:500 General:>Phs-rotation reversal SPS I
_:2311:501 General:>Invert Phases SPS I
General
_:2311:319 General:Phase sequence ABC SPS O
_:2311:320 General:Phase sequence ACB SPS O
_:2311:321 General:Freq.out of oper.range SPS O
_:2311:322 General:f sys MV O
_:2311:323 General:f track MV O
Measuring Point I-3ph
No. Information Data Class
(Type)
Type
General
_:8881:319 CT 3-phase:Phases AB inverted SPS O
_:8881:320 CT 3-phase:Phases BC inverted SPS O
_:8881:321 CT 3-phase:Phases AC inverted SPS O
CT 1
_:3841:300 CT 1:Sampled val. current SAV O
CT 2
_:3842:300 CT 2:Sampled val. current SAV O
CT 3
_:3843:300 CT 3:Sampled val. current SAV O
CT 4
_:3844:300 CT 4:Sampled val. current SAV O
Brk.wire det.
_:5581:82 Brk.wire det.:>Block function SPS I
_:5581:54 Brk.wire det.:Inactive SPS O
_:5581:52 Brk.wire det.:Behavior ENS O
_:5581:53 Brk.wire det.:Health ENS O
_:5581:301 Brk.wire det.:Phs A BW suspected SPS O
_:5581:302 Brk.wire det.:Phs B BW suspected SPS O
_:5581:303 Brk.wire det.:Phs C BW suspected SPS O
_:5581:304 Brk.wire det.:Phase A broken wire SPS O
_:5581:305 Brk.wire det.:Phase B broken wire SPS O
_:5581:306 Brk.wire det.:Phase C broken wire SPS O
_:5581:307 Brk.wire det.:Broken wire suspected SPS O
_:5581:308 Brk.wire det.:Broken wire confirmed SPS O
Supv. balan. I
_:2491:82 Supv. balan. I:>Block function SPS I
_:2491:54 Supv. balan. I:Inactive SPS O
_:2491:52 Supv. balan. I:Behavior ENS O
_:2491:53 Supv. balan. I:Health ENS O
5.9
Power-System Data
5.9 Information List
SIPROTEC 5, Fault Recorder, Manual 131
C53000-G5040-C018-5, Edition 11.2017

Siemens SIPROTEC 5 Specifications

General

Series	SIPROTEC 5
Communication Protocols	IEC 61850, DNP3, Modbus
Cybersecurity	Role-based access control, secure communication
Modular Design	Yes
Hardware Redundancy	Optional
Operating Temperature	-25°C to +70°C
Digital Inputs	Configurable, number depends on I/O modules
Digital Outputs	Configurable, number depends on I/O modules
Analog Inputs	Configurable, number depends on I/O modules
Current Transformer Inputs	Configurable, number depends on I/O modules
Voltage Transformer Inputs	Configurable, number depends on I/O modules
Time Synchronization	IRIG-B, SNTP, PTP
Protection Functions	Overcurrent, Differential, Distance, Over/Under Voltage, Frequency
Housing	19-inch Rack Mount
Dimensions	Depends on module configuration
Weight	Depends on module configuration
Voltage Input	24V DC, 48V DC, 110V DC, 125V DC, 220V DC, 250V DC
