Siemens SIPROTEC 5 User Manual

No. Information Data Class
(Type)
Type
_:2491:71 Supv. balan. I:Failure SPS O
Supv. ph.seq.I
_:2551:82 Supv. ph.seq.I:>Block function SPS I
_:2551:54 Supv. ph.seq.I:Inactive SPS O
_:2551:52 Supv. ph.seq.I:Behavior ENS O
_:2551:53 Supv. ph.seq.I:Health ENS O
_:2551:71 Supv. ph.seq.I:Failure SPS O
Supv. sum I
_:2431:82 Supv. sum I:>Block function SPS I
_:2431:54 Supv. sum I:Inactive SPS O
_:2431:52 Supv. sum I:Behavior ENS O
_:2431:53 Supv. sum I:Health ENS O
_:2431:71 Supv. sum I:Failure SPS O
Supv.ADC sum I
_:2401:82 Supv.ADC sum I:>Block function SPS I
_:2401:54 Supv.ADC sum I:Inactive SPS O
_:2401:52 Supv.ADC sum I:Behavior ENS O
_:2401:53 Supv.ADC sum I:Health ENS O
_:2401:71 Supv.ADC sum I:Failure SPS O
Saturat. det.
_:17731:54 Saturat. det.:Inactive SPS O
_:17731:52 Saturat. det.:Behavior ENS O
_:17731:53 Saturat. det.:Health ENS O
Measuring Point I-1ph
No.
Information Data Class
(Type)
Type
CT 1
_:3841:300 CT 1:Sampled val. current SAV O
Measuring Point V-3ph
No.
Information Data Class
(Type)
Type
General
_:8911:315 VT 3-phase:Phases AB inverted SPS O
_:8911:316 VT 3-phase:Phases BC inverted SPS O
_:8911:317 VT 3-phase:Phases AC inverted SPS O
VT 1
_:3811:300 VT 1:Sampled val. voltage SAV O
VT 2
_:3812:300 VT 2:Sampled val. voltage SAV O
VT 3
_:3813:300 VT 3:Sampled val. voltage SAV O
VT 4
_:3814:300 VT 4:Sampled val. voltage SAV O
Power-System Data
5.9 Information List
132 SIPROTEC 5, Fault Recorder, Manual
C53000-G5040-C018-5, Edition 11.2017

Siemens SIPROTEC 5 Specifications

General

Series	SIPROTEC 5
Communication Protocols	IEC 61850, DNP3, Modbus
Cybersecurity	Role-based access control, secure communication
Modular Design	Yes
Hardware Redundancy	Optional
Operating Temperature	-25°C to +70°C
Digital Inputs	Configurable, number depends on I/O modules
Digital Outputs	Configurable, number depends on I/O modules
Analog Inputs	Configurable, number depends on I/O modules
Current Transformer Inputs	Configurable, number depends on I/O modules
Voltage Transformer Inputs	Configurable, number depends on I/O modules
Time Synchronization	IRIG-B, SNTP, PTP
Protection Functions	Overcurrent, Differential, Distance, Over/Under Voltage, Frequency
Housing	19-inch Rack Mount
Dimensions	Depends on module configuration
Weight	Depends on module configuration
Voltage Input	24V DC, 48V DC, 110V DC, 125V DC, 220V DC, 250V DC
