Siemens SIPROTEC 5 User Manual

Addr. Parameter C Setting Options Default Setting
_:104 Time sync.:Time source
1 channel
•
Ch1
•
Ch2
_:105 Time sync.:Time source
2
•
none
•
IRIG-B
•
DCF77
•
PI
•
SNTP
•
IEC 60870-5-103
•
PROFIBUS DP
•
Modbus
•
DNP3
•
IEEE 1588
•
IEC 60870-5-104
none
_:106 Time sync.:Time source
2 port
•
port J
•
port F
•
port E
•
port P
•
port N
•
port G
_:107 Time sync.:Time source
2 channel
•
Ch1
•
Ch2
_:108 Time sync.:Time zone
time source 1
•
UTC
•
local
local
_:109 Time sync.:Time zone
time source 2
•
UTC
•
local
local
_:101 Time sync.:Fault indica-
tion after
0 s to 3600 s 600 s
Information List
No.
Information Data Class
(Type)
Type
Time managem.
_:300 Time managem.:Daylight saving time SPS O
_:301 Time managem.:Clock set manually SPS O
No. Information Data Class
(Type)
Type
Time sync.
_:303 Time sync.:Status time source 1 SPS O
_:304 Time sync.:Status time source 2 SPS O
_:305 Time sync.:Time sync. error SPS O
_:306 Time sync.:Leap second SPS O
_:307 Time sync.:High accuracy SPS O
3.4.5
System Functions
3.4 Date and Time Synchronization
86 SIPROTEC 5, Fault Recorder, Manual
C53000-G5040-C018-5, Edition 11.2017

Siemens SIPROTEC 5 Specifications

General

Series	SIPROTEC 5
Communication Protocols	IEC 61850, DNP3, Modbus
Cybersecurity	Role-based access control, secure communication
Modular Design	Yes
Hardware Redundancy	Optional
Operating Temperature	-25°C to +70°C
Digital Inputs	Configurable, number depends on I/O modules
Digital Outputs	Configurable, number depends on I/O modules
Analog Inputs	Configurable, number depends on I/O modules
Current Transformer Inputs	Configurable, number depends on I/O modules
Voltage Transformer Inputs	Configurable, number depends on I/O modules
Time Synchronization	IRIG-B, SNTP, PTP
Protection Functions	Overcurrent, Differential, Distance, Over/Under Voltage, Frequency
Housing	19-inch Rack Mount
Dimensions	Depends on module configuration
Weight	Depends on module configuration
Voltage Input	24V DC, 48V DC, 110V DC, 125V DC, 220V DC, 250V DC
