Siemens SIPROTEC 5 - Settings

[dw_measuring-transducer-setting, 1, en_US]
Figure 6-55
Parameter Settings and Representation of an Input Signal Greater than 10 V
Settings
Addr.
Parameter C Setting Options Default Setting
MT fast #
_:101 MT in #:TD input-signal
type
•
Voltage input
•
Current input
Current input
6.5.6.5
Function-Group Types
6.5 Function-Group Type Analog Units
194 SIPROTEC 5, Fault Recorder, Manual
C53000-G5040-C018-5, Edition 11.2017
