Siemens SIPROTEC 5 User Manual

Function-Group Type Voltage/current 1-Phase
Overview of Functions
The Voltage/current 1-phase function group determines the measured values from the connected current
and voltage channels.
The following function blocks work in the Recorder routing VI function:
•
Routing f
•
Routing I
•
Routing power
•
Routing V
i
i
NOTE
The Voltage/current 1-phase function group works with a voltage measuring point, with a current meas-
uring point, or with a voltage and current measuring point. Depending on the connected measuring points,
the voltage, frequency and power functions (measured values, trigger and recorder routing functions) are
not available.
For more information about the embedding of the functions in the device, please refer to chapter 2.1 Function
Embedding in the Device.
The entire function scope of the application templates can be found in chapter 4.2 Application Template and
Functional Scope for the Fault Recorder .
Structure of the Function Group
The function group Voltage/current 1-phase always contains the function block General, which cannot be
deleted.
You can load the trigger functions required for your application in the function group. These trigger functions
are available in the Global DIGSI 5 library. Trigger functions that are not needed can be deleted again from the
function group.
The following figure shows the structure of the function group Voltage/current 1-phase:
6.2
6.2.1
6.2.2
Function-Group Types
6.2 Function-Group Type Voltage/current 1-Phase
140 SIPROTEC 5, Fault Recorder, Manual
C53000-G5040-C018-5, Edition 11.2017

Siemens SIPROTEC 5 Specifications

General

Series	SIPROTEC 5
Communication Protocols	IEC 61850, DNP3, Modbus
Cybersecurity	Role-based access control, secure communication
Modular Design	Yes
Hardware Redundancy	Optional
Operating Temperature	-25°C to +70°C
Digital Inputs	Configurable, number depends on I/O modules
Digital Outputs	Configurable, number depends on I/O modules
Analog Inputs	Configurable, number depends on I/O modules
Current Transformer Inputs	Configurable, number depends on I/O modules
Voltage Transformer Inputs	Configurable, number depends on I/O modules
Time Synchronization	IRIG-B, SNTP, PTP
Protection Functions	Overcurrent, Differential, Distance, Over/Under Voltage, Frequency
Housing	19-inch Rack Mount
Dimensions	Depends on module configuration
Weight	Depends on module configuration
Voltage Input	24V DC, 48V DC, 110V DC, 125V DC, 220V DC, 250V DC
