Addr. Parameter C Setting Options Default Setting
_:13111:107 Channel 1:Range active
•
0
•
1
false
_:13111:104 Channel 1:Conversion
factor
1 to 1000000 100
_:13111:105 Channel 1:Upper limit 0.00 mA to 20.00 mA 20.00 mA
_:13111:109 Channel 1:Upper limit -
Sensor
-1000000 to 1000000 100
_:13111:106 Channel 1:Lower limit 0.00 mA to 20.00 mA 4.00 mA
_:13111:110 Channel 1:Lower limit -
Sensor
-1000000 to 1000000 100
Information List
No. Information Data Class
(Type)
Type
General
_:2311:53 General:Health ENS O
_:2311:56 General:Failure SPS O
Channel 1
_:13111:53 Channel 1:Health ENS O
_:13111:71 Channel 1:Failure SPS O
_:13111:301 Channel 1:20-mA output scale MV O
_:13111:302 Channel 1:20-mA output raw MV O
20-mA Unit Serial
Overview
The function 20-mA unit Serial:
•
Provides serial communications with a 20-mA unit via the Modbus protocol and records the values meas-
ured by the 20-mA unit
•
Transforms the measured 20-mA values into slowly changing process variables such as temperature or
gas pressure
•
Makes the recorded process tags available to CFC, GOOSE, protocols and the device display
•
Monitors communication with the 20-mA unit
The function 20-mA unit Serial is structured in the same way as the function 20-mA Unit Ether.. The mode of
operation is also identical. The only difference is that the measured values are transferred to the communica-
tion module via a serial connection instead of an Ethernet connection.
You can find more information in Chapter 6.5.3.2 Structure of the Function.
Application and Setting Notes
Parameter: Port
•
Default setting (_:2311:103) Port = Port J
With the Port setting, you specify the slot for the communication module that will be used for the connection
with an external 20-mA unit.
Parameter: Channel number
•
Default setting (_:2311:105) Channel number = 1
6.5.3.8
6.5.4
6.5.4.1
6.5.4.2
Function-Group Types
6.5 Function-Group Type Analog Units
180 SIPROTEC 5, Fault Recorder, Manual
C53000-G5040-C018-5, Edition 11.2017
