Application Template and Functional Scope for the Fault Recorder
Application templates are available in DIGSI 5 for the applications of the fault recorder. The application
template contains the basic configurations, required functions, and default settings.
To load the application templates to the device, the following minimum hardware configuration requirements
must be met:
Application Template
Template 1 Fault Recorder N1: 1/3, 11 BIs, 9 BOs, 4I, 4V
Template 2 Fault Recorder N5: 1/2, 19 BIs, 15 BOs, 8I, 8V
Template 3 Fault Recorder N6: 1/1, 43 BIs, 33 BOs, 20I, 20V
Template 4 Fault Recorder N2: 1/3, 11 BIs, 3 BOs, 8V
The following table shows the functional scope and the function-point requirements of the application
templates for the fault recorders:
Table 4-1 Functional Scope of the Application Templates for the Fault Recorder
Function
Function Points
Default Setting in the Application Template
Template 1
Template 2
Template 3
Template 4
Hardware quantity structure expandable (I/O) 1 1 1 1
FG Voltage (FG V) 0 0 0 2
FG Voltage/Current (FG VI) 1 2 5 0
FG ComModule 1 1 1 1
FG Recording 1 1 1 1
FG Simulation 1 1 1 1
FG Analog units 0 0 0 0
Phasor Measurement Unit (PMU) 40 0 0 0 0
Power-system data (power system) 1 1 1 1
Fast-scan recorder 1 1 1 1
Slow-scan recorder
*
40 1 1 1 1
Continuous recorder
*
25 1 1 1 1
Trend recorder
*
25 0 0 0 0
Measured values, extended: Min, max,
average
0 0 0 0
Voltage trigger 1 2 5 2
Current trigger 1 2 5 0
Frequency trigger 1 2 5 2
Power trigger 1 2 5 0
Recorder routing VI 1 2 5 0
Recorder routing V 0 0 0 2
PQ 10/12cyc 25 0 0 0 0
PQ trend 25 0 0 0 0
PQ flicker 25 0 0 0 0
Measuring inputs,1-phase voltage 0 0 0 0
Measuring inputs, 3-phase voltage 1 2 5 2
Measuring inputs, 1-phase current 0 0 0 0
Measuring inputs, 3-phase current 1 2 5 0
4.2
Applications
4.2 Application Template and Functional Scope for the Fault Recorder
SIPROTEC 5, Fault Recorder, Manual 105
C53000-G5040-C018-5, Edition 11.2017
