Addr. Parameter C Setting Options Default Setting
_:9751:105 Trig. I fund 1:Max.
trigger
1 A @ 100 Irated 0.030 A to 100.000 A 1.200 A
5 A @ 100 Irated 0.15 A to 500.00 A 6.00 A
1 A @ 50 Irated 0.030 A to 50.000 A 1.200 A
5 A @ 50 Irated 0.15 A to 250.00 A 6.00 A
1 A @ 1.6 Irated 0.001 A to 1.600 A 1.200 A
5 A @ 1.6 Irated 0.005 A to 8.000 A 6.000 A
_:9751:113 Trig. I fund 1:Max.
trigger hysteresis
0.900 p.u. to 0.990 p.u. 0.980 p.u.
_:9751:102 Trig. I fund 1:Min.
trigger active
•
no
•
yes
yes
_:9751:106 Trig. I fund 1:Min.
trigger
1 A @ 100 Irated 0.030 A to 100.000 A 0.800 A
5 A @ 100 Irated 0.15 A to 500.00 A 4.00 A
1 A @ 50 Irated 0.030 A to 50.000 A 0.800 A
5 A @ 50 Irated 0.15 A to 250.00 A 4.00 A
1 A @ 1.6 Irated 0.001 A to 1.600 A 0.800 A
5 A @ 1.6 Irated 0.005 A to 8.000 A 4.000 A
_:9751:114 Trig. I fund 1:Min.
trigger hysteresis
1.010 p.u. to 1.100 p.u. 1.020 p.u.
_:9751:103 Trig. I fund 1:dM/dt rise
active
•
no
•
yes
no
_:9751:107 Trig. I fund 1:dM/dt rise
(/Filter time)
1 A @ 100 Irated 0.030 A to 100.000 A 0.300 A
5 A @ 100 Irated 0.15 A to 500.00 A 1.50 A
1 A @ 50 Irated 0.030 A to 50.000 A 0.300 A
5 A @ 50 Irated 0.15 A to 250.00 A 1.50 A
1 A @ 1.6 Irated 0.001 A to 1.600 A 0.300 A
5 A @ 1.6 Irated 0.005 A to 8.000 A 1.500 A
_:9751:115 Trig. I fund 1:dM/dt rise
hysteresis
0.900 p.u. to 0.990 p.u. 0.980 p.u.
_:9751:104 Trig. I fund 1:dM/dt drop
active
•
no
•
yes
no
_:9751:108 Trig. I fund 1:dM/dt drop
(/Filter time)
1 A @ 100 Irated 0.030 A to 100.000 A 0.300 A
5 A @ 100 Irated 0.15 A to 500.00 A 1.50 A
1 A @ 50 Irated 0.030 A to 50.000 A 0.300 A
5 A @ 50 Irated 0.15 A to 250.00 A 1.50 A
1 A @ 1.6 Irated 0.001 A to 1.600 A 0.300 A
5 A @ 1.6 Irated 0.005 A to 8.000 A 1.500 A
_:9751:116 Trig. I fund 1:dM/dt drop
hysteresis
0.900 p.u. to 0.990 p.u. 0.980 p.u.
_:9751:112 Trig. I fund 1:Filter time 2 cycles to 250 cycles 2 cycles
Information List
No.
Information Data Class
(Type)
Type
Trig. I RMS 1
_:9781:54 Trig. I RMS 1:Inactive SPS O
_:9781:52 Trig. I RMS 1:Behavior ENS O
_:9781:53 Trig. I RMS 1:Health ENS O
_:9781:301 Trig. I RMS 1:Trigger active SPS O
7.4.2.7
Fault Recorder
7.4 Trigger Functions 1-Phase
284 SIPROTEC 5, Fault Recorder, Manual
C53000-G5040-C018-5, Edition 11.2017
