Addr. Parameter C Setting Options Default Setting
_:9781:105 Trig. I RMS 1:Max.
trigger
1 A @ 100 Irated 0.030 A to 100.000 A 1.200 A
5 A @ 100 Irated 0.15 A to 500.00 A 6.00 A
1 A @ 50 Irated 0.030 A to 50.000 A 1.200 A
5 A @ 50 Irated 0.15 A to 250.00 A 6.00 A
1 A @ 1.6 Irated 0.001 A to 1.600 A 1.200 A
5 A @ 1.6 Irated 0.005 A to 8.000 A 6.000 A
_:9781:113 Trig. I RMS 1:Max.
trigger hysteresis
0.900 p.u. to 0.990 p.u. 0.980 p.u.
_:9781:102 Trig. I RMS 1:Min. trigger
active
•
no
•
yes
yes
_:9781:106 Trig. I RMS 1:Min. trigger 1 A @ 100 Irated 0.030 A to 100.000 A 0.800 A
5 A @ 100 Irated 0.15 A to 500.00 A 4.00 A
1 A @ 50 Irated 0.030 A to 50.000 A 0.800 A
5 A @ 50 Irated 0.15 A to 250.00 A 4.00 A
1 A @ 1.6 Irated 0.001 A to 1.600 A 0.800 A
5 A @ 1.6 Irated 0.005 A to 8.000 A 4.000 A
_:9781:114 Trig. I RMS 1:Min. trigger
hysteresis
1.010 p.u. to 1.100 p.u. 1.020 p.u.
_:9781:103 Trig. I RMS 1:dM/dt rise
active
•
no
•
yes
no
_:9781:107 Trig. I RMS 1:dM/dt rise (/
Filter time)
1 A @ 100 Irated 0.030 A to 100.000 A 0.300 A
5 A @ 100 Irated 0.15 A to 500.00 A 1.50 A
1 A @ 50 Irated 0.030 A to 50.000 A 0.300 A
5 A @ 50 Irated 0.15 A to 250.00 A 1.50 A
1 A @ 1.6 Irated 0.001 A to 1.600 A 0.300 A
5 A @ 1.6 Irated 0.005 A to 8.000 A 1.500 A
_:9781:115 Trig. I RMS 1:dM/dt rise
hysteresis
0.900 p.u. to 0.990 p.u. 0.980 p.u.
_:9781:104 Trig. I RMS 1:dM/dt drop
active
•
no
•
yes
no
_:9781:108 Trig. I RMS 1:dM/dt drop
(/Filter time)
1 A @ 100 Irated 0.030 A to 100.000 A 0.300 A
5 A @ 100 Irated 0.15 A to 500.00 A 1.50 A
1 A @ 50 Irated 0.030 A to 50.000 A 0.300 A
5 A @ 50 Irated 0.15 A to 250.00 A 1.50 A
1 A @ 1.6 Irated 0.001 A to 1.600 A 0.300 A
5 A @ 1.6 Irated 0.005 A to 8.000 A 1.500 A
_:9781:116 Trig. I RMS 1:dM/dt drop
hysteresis
0.900 p.u. to 0.990 p.u. 0.980 p.u.
_:9781:112 Trig. I RMS 1:Filter time 2 cycles to 250 cycles 2 cycles
Trig. I fund 1
_:9751:1 Trig. I fund 1:Mode
•
off
•
on
•
test
off
_:9751:101 Trig. I fund 1:Max.
trigger active
•
no
•
yes
yes
Fault Recorder
7.4 Trigger Functions 1-Phase
SIPROTEC 5, Fault Recorder, Manual 283
C53000-G5040-C018-5, Edition 11.2017
