Addr. Parameter C Setting Options Default Setting
_:9841:108 Trigger I1 1:dM/dt drop
(/Filter time)
1 A @ 100 Irated 0.030 A to 100.000 A 0.300 A
5 A @ 100 Irated 0.15 A to 500.00 A 1.50 A
1 A @ 50 Irated 0.030 A to 50.000 A 0.300 A
5 A @ 50 Irated 0.15 A to 250.00 A 1.50 A
1 A @ 1.6 Irated 0.001 A to 1.600 A 0.300 A
5 A @ 1.6 Irated 0.005 A to 8.000 A 1.500 A
_:9841:116 Trigger I1 1:dM/dt drop
hysteresis
0.900 p.u. to 0.990 p.u. 0.980 p.u.
_:9841:112 Trigger I1 1:Filter time 2 cycles to 250 cycles 2 cycles
Trigger I2 1
_:9871:1 Trigger I2 1:Mode
•
off
•
on
•
test
off
_:9871:101 Trigger I2 1:Max. trigger
active
•
no
•
yes
yes
_:9871:105 Trigger I2 1:Max. trigger 1 A @ 100 Irated 0.030 A to 100.000 A 1.200 A
5 A @ 100 Irated 0.15 A to 500.00 A 6.00 A
1 A @ 50 Irated 0.030 A to 50.000 A 1.200 A
5 A @ 50 Irated 0.15 A to 250.00 A 6.00 A
1 A @ 1.6 Irated 0.001 A to 1.600 A 1.200 A
5 A @ 1.6 Irated 0.005 A to 8.000 A 6.000 A
_:9871:113 Trigger I2 1:Max. trigger
hysteresis
0.900 p.u. to 0.990 p.u. 0.980 p.u.
_:9871:103 Trigger I2 1:dM/dt rise
active
•
no
•
yes
no
_:9871:107 Trigger I2 1:dM/dt rise (/
Filter time)
1 A @ 100 Irated 0.030 A to 100.000 A 0.300 A
5 A @ 100 Irated 0.15 A to 500.00 A 1.50 A
1 A @ 50 Irated 0.030 A to 50.000 A 0.300 A
5 A @ 50 Irated 0.15 A to 250.00 A 1.50 A
1 A @ 1.6 Irated 0.001 A to 1.600 A 0.300 A
5 A @ 1.6 Irated 0.005 A to 8.000 A 1.500 A
_:9871:115 Trigger I2 1:dM/dt rise
hysteresis
0.900 p.u. to 0.990 p.u. 0.980 p.u.
_:9871:112 Trigger I2 1:Filter time 2 cycles to 250 cycles 2 cycles
Information List
No.
Information Data Class
(Type)
Type
Trig. I fund 1
_:9751:54 Trig. I fund 1:Inactive SPS O
_:9751:52 Trig. I fund 1:Behavior ENS O
_:9751:53 Trig. I fund 1:Health ENS O
_:9751:301 Trig. I fund 1:Trigger active SPS O
Trig. I RMS 1
_:9781:54 Trig. I RMS 1:Inactive SPS O
_:9781:52 Trig. I RMS 1:Behavior ENS O
_:9781:53 Trig. I RMS 1:Health ENS O
_:9781:301 Trig. I RMS 1:Trigger active SPS O
7.5.2.10
Fault Recorder
7.5 Trigger Functions 3-Phase
330 SIPROTEC 5, Fault Recorder, Manual
C53000-G5040-C018-5, Edition 11.2017
