Siemens SIPROTEC 5 User Manual

Recorder Functions
Fast-Scan Recorder
Setting Values
Fast-Scan Recorder Setting Range Increment
Memory capacity 0.200 GB to 15.000 GB Increments of 1
Maximum record time 1.0 s to 90.0 s Increments of 0.1
Pre-trigger time 0 s to 3.0 s Increments of 0.1
Post-trigger time 1.0 s to 90.0 s Increments of 0.1
Manual record time 1.0 s to 90.0 s Increments of 0.1
Sampling frequency 1 kHz to 16 kHz Increments of 1, 2, 4, 8, 16
Retrigger blocking time 0.0 s to 3600 s Increments of 0.1
Number of Recorder Instances
Fast-scan recorder 1 (fix)
Signals to be Recorded
Refer to Number of Routable Measured Values (MV) and Binary Tracks (SPS), Page 439
Trigger
Frequency trigger
Power trigger
Voltage trigger
Current trigger
Slow-Scan Recorder
Setting Values
Slow-Scan Recorder
Setting Range Increment
Memory capacity 0.200 GB to 14.800 GB Increments of 1
Maximum record time 1 min to 90 min Increments of 1
Pre-trigger time 0 s to 90 s Increments of 1
Post-trigger time 1 min to 90 min Increments of 1
Manual record time 1 min to 90 min Increments of 1
Averaging time 1 to 3000 periods Increments of 1
Retrigger blocking time 0 min to 240 min Increments of 1
Number of Recorder Instances
Slow-scan recorder
0 to 2
Signals to be Recorded
Refer to Number of Routable Measured Values (MV) and Binary Tracks (SPS), Page 439
Trigger
Frequency trigger
11.4
11.4.1
11.4.2
Technical Data
11.4 Recorder Functions
438 SIPROTEC 5, Fault Recorder, Manual
C53000-G5040-C018-5, Edition 11.2017

Siemens SIPROTEC 5 Specifications

General

Series	SIPROTEC 5
Communication Protocols	IEC 61850, DNP3, Modbus
Cybersecurity	Role-based access control, secure communication
Modular Design	Yes
Hardware Redundancy	Optional
Operating Temperature	-25°C to +70°C
Digital Inputs	Configurable, number depends on I/O modules
Digital Outputs	Configurable, number depends on I/O modules
Analog Inputs	Configurable, number depends on I/O modules
Current Transformer Inputs	Configurable, number depends on I/O modules
Voltage Transformer Inputs	Configurable, number depends on I/O modules
Time Synchronization	IRIG-B, SNTP, PTP
Protection Functions	Overcurrent, Differential, Distance, Over/Under Voltage, Frequency
Housing	19-inch Rack Mount
Dimensions	Depends on module configuration
Weight	Depends on module configuration
Voltage Input	24V DC, 48V DC, 110V DC, 125V DC, 220V DC, 250V DC
