Siemens SIPROTEC 5 User Manual

Measurands and Recorder Routing Functions
Measurands
Properties of Measurands
With the SIPROTEC 5 device, various recording options are available for supervision and evaluation of the
power-system voltage quality. Measurands are measured or calculated in 3-phase systems.
To achieve the best power-quality supervision, the following tables contain recommendations on routing the
measurands in DIGSI 5.
Using Measurands
Function Description
The sampled values (SAV) are automatically routed to the Fast-scan recorder and cannot be changed by the
user. The measured values, on the other hand, are formed from the sampled values. You can route the meas-
ured values manually in Information routing.
i
i
NOTE
The Voltage-current 3-phase function group also works without an assigned voltage measuring point. In
this case the voltage, frequency and power functions (measured value, trigger and recorder routing func-
tions) are not available.
After you have instantiated the Recorder routing function and the desired function blocks, you can assign the
measured values to the individual recorders in the Information routing.
7.6
7.6.1
7.6.1.1
7.6.1.2
Fault Recorder
7.6 Measurands and Recorder Routing Functions
348 SIPROTEC 5, Fault Recorder, Manual
C53000-G5040-C018-5, Edition 11.2017

Siemens SIPROTEC 5 Specifications

General

Series	SIPROTEC 5
Communication Protocols	IEC 61850, DNP3, Modbus
Cybersecurity	Role-based access control, secure communication
Modular Design	Yes
Hardware Redundancy	Optional
Operating Temperature	-25°C to +70°C
Digital Inputs	Configurable, number depends on I/O modules
Digital Outputs	Configurable, number depends on I/O modules
Analog Inputs	Configurable, number depends on I/O modules
Current Transformer Inputs	Configurable, number depends on I/O modules
Voltage Transformer Inputs	Configurable, number depends on I/O modules
Time Synchronization	IRIG-B, SNTP, PTP
Protection Functions	Overcurrent, Differential, Distance, Over/Under Voltage, Frequency
Housing	19-inch Rack Mount
Dimensions	Depends on module configuration
Weight	Depends on module configuration
Voltage Input	24V DC, 48V DC, 110V DC, 125V DC, 220V DC, 250V DC
