PQ Flicker
No. Information Data Class
(Type)
Type
PQ flicker
_:300 PQ flicker:Pst ph WYE O
_:301 PQ flicker:Plt ph WYE O
_:302 PQ flicker:Pinst ph WYE O
_:303 PQ flicker:Pimx ph WYE O
_:304 PQ flicker:Pst pp DEL O
_:305 PQ flicker:Plt pp DEL O
_:306 PQ flicker:Pinst pp DEL O
_:307 PQ flicker:Pimx pp DEL O
Recorder Routing VI 1-Phase
Overview of Functions
You can find more information on the Recorder routing VI function in chapter 6.2.2 Structure of the Function
Group.
Structure of the Function
Within the Voltage/current 1-phase function group, the Recorder routing VI function can be operated only
once.
You can find more information on the Recorder routing VI function in the chapters 6.2.2 Structure of the
Function Group and 7.6.1.2 Using Measurands .
Application and Setting Notes
Parameters of the Recorder Routing VI Function
The Recorder routing VI function can only be added to the Voltage/current 1-phase function group.
The procedure is described in chapter 7.1.2 Step 1: Creating a New Project and Adding a New Device and in
the DIGSI Help.
Information List
Frequency
No.
Information Data Class
(Type)
Type
Routing f
_:301 Routing f:f MV O
Current
No.
Information Data Class
(Type)
Type
Routing I
_:300 Routing I:Iph rms WYE O
_:301 Routing I:IN rms MV O
_:302 Routing I:Iph fd. WYE O
_:303 Routing I:IN fd. CMV O
_:304 Routing I:I0 CMV O
7.6.3
7.6.3.1
7.6.3.2
7.6.3.3
7.6.3.4
Fault Recorder
7.6 Measurands and Recorder Routing Functions
356 SIPROTEC 5, Fault Recorder, Manual
C53000-G5040-C018-5, Edition 11.2017
