Siemens SIPROTEC 5 User Manual

Number Device-Diagnosis Log
4729 Device bus error (repeated):
•
Check the module configuration and the module connections.
•
Contact the Customer Support Center.
4733 Incorrect hardware configuration:
Synchronize the hardware configuration of the device with DIGSI.
5037-5048 Wrong module 1-12 detected:
Synchronize the hardware configuration of the device with DIGSI.
5031-5035 Identified wrong plug-in module on plug-in module position E/F/M/N/P:
Synchronize the hardware configuration of the device with DIGSI.
Wrong application configuration:
Search for the cause in the operational log and load a valid configuration to the device.
3640, 4514 Data-structure error:
Contact the Customer Support Center.
956 Firmware-version error:
Contact the Customer Support Center.
2013, 2025 Signature error:
Contact the Customer Support Center.
CFC error:
In DIGSI, check your CFC chart for the cause.
5050-5061 Binary-output error in module 1 - 12:
Contact the Customer Support Center.
5088, 5089 A missing display configuration was established:
Synchronize the hardware configuration of the device with DIGSI.
Defect Severity 4 (Group Alarm)
Errors of defect severity 4 are not device failures in the classical meaning. These errors do not affect the device
hardware and are not detected or reported by internal device supervision functions. The condition of the
defect severity 4 – the group alarm – is set user-specifically by the binary input signal (_:503) >Group
alarm . If the binary input signal is reset, the device is no longer in the Group alarm condition and all func-
tions return to the normal operating state.
If the group alarm is generated, the device reacts as follows:
•
The group indication
(_:300) Group alarm is generated and recorded in the operational log.
•
The life contact is terminated.
•
The red Error LED is activated.
•
All protection and automation functions are blocked.
•
The device remains in operation, does not carry out any restart (reset), and does not switch to the safe
condition (Fallback mode).
•
The signals managed internally are marked with the invalid quality attribute. Signals managed inter-
nally are, for example, measured values, binary input and output signals, GOOSE and CFC signals.
In the delivery condition, every device has the CFC chart Process mode inactive, that initiates the Group
alarm (see chapter 8.9 Group Indications).
Life contact
Is terminated in case of Group alarm
Red error LED Is initiated in case of Group alarm
8.8.5
Supervision Functions
8.8 Error Responses and Corrective Measures
SIPROTEC 5, Fault Recorder, Manual 407
C53000-G5040-C018-5, Edition 11.2017
