Addr. Parameter C Setting Options Default Setting
_:9811:107 Trigger I0 1:dM/dt rise (/
Filter time)
1 A @ 100 Irated 0.030 A to 100.000 A 0.300 A
5 A @ 100 Irated 0.15 A to 500.00 A 1.50 A
1 A @ 50 Irated 0.030 A to 50.000 A 0.300 A
5 A @ 50 Irated 0.15 A to 250.00 A 1.50 A
1 A @ 1.6 Irated 0.001 A to 1.600 A 0.300 A
5 A @ 1.6 Irated 0.005 A to 8.000 A 1.500 A
_:9811:115 Trigger I0 1:dM/dt rise
hysteresis
0.900 p.u. to 0.990 p.u. 0.980 p.u.
_:9811:112 Trigger I0 1:Filter time 2 cycles to 250 cycles 2 cycles
Trigger I1 1
_:9841:1 Trigger I1 1:Mode
•
off
•
on
•
test
off
_:9841:101 Trigger I1 1:Max. trigger
active
•
no
•
yes
yes
_:9841:105 Trigger I1 1:Max. trigger 1 A @ 100 Irated 0.030 A to 100.000 A 1.200 A
5 A @ 100 Irated 0.15 A to 500.00 A 6.00 A
1 A @ 50 Irated 0.030 A to 50.000 A 1.200 A
5 A @ 50 Irated 0.15 A to 250.00 A 6.00 A
1 A @ 1.6 Irated 0.001 A to 1.600 A 1.200 A
5 A @ 1.6 Irated 0.005 A to 8.000 A 6.000 A
_:9841:113 Trigger I1 1:Max. trigger
hysteresis
0.900 p.u. to 0.990 p.u. 0.980 p.u.
_:9841:102 Trigger I1 1:Min. trigger
active
•
no
•
yes
yes
_:9841:106 Trigger I1 1:Min. trigger 1 A @ 100 Irated 0.030 A to 100.000 A 0.800 A
5 A @ 100 Irated 0.15 A to 500.00 A 4.00 A
1 A @ 50 Irated 0.030 A to 50.000 A 0.800 A
5 A @ 50 Irated 0.15 A to 250.00 A 4.00 A
1 A @ 1.6 Irated 0.001 A to 1.600 A 0.800 A
5 A @ 1.6 Irated 0.005 A to 8.000 A 4.000 A
_:9841:114 Trigger I1 1:Min. trigger
hysteresis
1.010 p.u. to 1.100 p.u. 1.020 p.u.
_:9841:103 Trigger I1 1:dM/dt rise
active
•
no
•
yes
no
_:9841:107 Trigger I1 1:dM/dt rise (/
Filter time)
1 A @ 100 Irated 0.030 A to 100.000 A 0.300 A
5 A @ 100 Irated 0.15 A to 500.00 A 1.50 A
1 A @ 50 Irated 0.030 A to 50.000 A 0.300 A
5 A @ 50 Irated 0.15 A to 250.00 A 1.50 A
1 A @ 1.6 Irated 0.001 A to 1.600 A 0.300 A
5 A @ 1.6 Irated 0.005 A to 8.000 A 1.500 A
_:9841:115 Trigger I1 1:dM/dt rise
hysteresis
0.900 p.u. to 0.990 p.u. 0.980 p.u.
_:9841:104 Trigger I1 1:dM/dt drop
active
•
no
•
yes
no
Fault Recorder
7.5 Trigger Functions 3-Phase
SIPROTEC 5, Fault Recorder, Manual 329
C53000-G5040-C018-5, Edition 11.2017
