Addr. Parameter C Setting Options Default Setting
_:9781:115 Trig. I RMS 1:+dM/dt
hysteresis
0.900 p.u. to 0.990 p.u. 0.980 p.u.
dM/dt drop (/Filter time)
_:9781:104 Trig. I RMS 1:-dM/dt
active
•
no
•
yes
no
_:9781:108 Trig. I RMS 1:-dM/dt
(Non-phs sel.)
1 A @ 100 Irated 0.030 A to 100.000 A 0.300 A
5 A @ 100 Irated 0.15 A to 500.00 A 1.50 A
1 A @ 50 Irated 0.030 A to 50.000 A 0.300 A
5 A @ 50 Irated 0.15 A to 250.00 A 1.50 A
1 A @ 1.6 Irated 0.001 A to 1.600 A 0.300 A
5 A @ 1.6 Irated 0.005 A to 8.000 A 1.500 A
_:9781:127 Trig. I RMS 1:-dM/dt phs
A
1 A @ 100 Irated 0.030 A to 100.000 A 0.300 A
5 A @ 100 Irated 0.15 A to 500.00 A 1.50 A
1 A @ 50 Irated 0.030 A to 50.000 A 0.300 A
5 A @ 50 Irated 0.15 A to 250.00 A 1.50 A
1 A @ 1.6 Irated 0.001 A to 1.600 A 0.300 A
5 A @ 1.6 Irated 0.005 A to 8.000 A 1.500 A
_:9781:128 Trig. I RMS 1:-dM/dt phs
B
1 A @ 100 Irated 0.030 A to 100.000 A 0.300 A
5 A @ 100 Irated 0.15 A to 500.00 A 1.50 A
1 A @ 50 Irated 0.030 A to 50.000 A 0.300 A
5 A @ 50 Irated 0.15 A to 250.00 A 1.50 A
1 A @ 1.6 Irated 0.001 A to 1.600 A 0.300 A
5 A @ 1.6 Irated 0.005 A to 8.000 A 1.500 A
_:9781:129 Trig. I RMS 1:-dM/dt phs
C
1 A @ 100 Irated 0.030 A to 100.000 A 0.300 A
5 A @ 100 Irated 0.15 A to 500.00 A 1.50 A
1 A @ 50 Irated 0.030 A to 50.000 A 0.300 A
5 A @ 50 Irated 0.15 A to 250.00 A 1.50 A
1 A @ 1.6 Irated 0.001 A to 1.600 A 0.300 A
5 A @ 1.6 Irated 0.005 A to 8.000 A 1.500 A
_:9781:116 Trig. I RMS 1:-dM/dt
hysteresis
0.900 p.u. to 0.990 p.u. 0.980 p.u.
Trigger I0 1
_:9811:1 Trigger I0 1:Mode
•
off
•
on
•
test
off
_:9811:101 Trigger I0 1:Max. trigger
active
•
no
•
yes
yes
_:9811:105 Trigger I0 1:Max. trigger 1 A @ 100 Irated 0.030 A to 100.000 A 1.200 A
5 A @ 100 Irated 0.15 A to 500.00 A 6.00 A
1 A @ 50 Irated 0.030 A to 50.000 A 1.200 A
5 A @ 50 Irated 0.15 A to 250.00 A 6.00 A
1 A @ 1.6 Irated 0.001 A to 1.600 A 1.200 A
5 A @ 1.6 Irated 0.005 A to 8.000 A 6.000 A
_:9811:113 Trigger I0 1:Max. trigger
hysteresis
0.900 p.u. to 0.990 p.u. 0.980 p.u.
_:9811:103 Trigger I0 1:dM/dt rise
active
•
no
•
yes
no
Fault Recorder
7.5 Trigger Functions 3-Phase
328 SIPROTEC 5, Fault Recorder, Manual
C53000-G5040-C018-5, Edition 11.2017

Siemens SIPROTEC 5 Specifications

General

Series	SIPROTEC 5
Communication Protocols	IEC 61850, DNP3, Modbus
Cybersecurity	Role-based access control, secure communication
Modular Design	Yes
Hardware Redundancy	Optional
Operating Temperature	-25°C to +70°C
Digital Inputs	Configurable, number depends on I/O modules
Digital Outputs	Configurable, number depends on I/O modules
Analog Inputs	Configurable, number depends on I/O modules
Current Transformer Inputs	Configurable, number depends on I/O modules
Voltage Transformer Inputs	Configurable, number depends on I/O modules
Time Synchronization	IRIG-B, SNTP, PTP
Protection Functions	Overcurrent, Differential, Distance, Over/Under Voltage, Frequency
Housing	19-inch Rack Mount
Dimensions	Depends on module configuration
Weight	Depends on module configuration
Voltage Input	24V DC, 48V DC, 110V DC, 125V DC, 220V DC, 250V DC
