Addr. Parameter C Setting Options Default Setting
_:19411:106 Trigger P 1:Min. trigger 1 A @ 100 Irated 0.20 W to 20000.00 W 80.00 W
5 A @ 100 Irated 0.60 W to 100000.00 W 400.00 W
_:19411:114 Trigger P 1:Min. trigger
hysteresis
1.010 p.u. to 1.100 p.u. 1.020 p.u.
_:19411:103 Trigger P 1:dM/dt rise
active
•
no
•
yes
no
_:19411:107 Trigger P 1:dM/dt rise (/
Filter time)
1 A @ 100 Irated 0.20 W to 20000.00 W 20.00 W
5 A @ 100 Irated 0.60 W to 100000.00 W 100.00 W
_:19411:115 Trigger P 1:dM/dt rise
hysteresis
0.900 p.u. to 0.990 p.u. 0.980 p.u.
_:19411:104 Trigger P 1:dM/dt drop
active
•
no
•
yes
no
_:19411:108 Trigger P 1:dM/dt drop (/
Filter time)
1 A @ 100 Irated 0.20 W to 20000.00 W 20.00 W
5 A @ 100 Irated 0.60 W to 100000.00 W 100.00 W
_:19411:116 Trigger P 1:dM/dt drop
hysteresis
0.900 p.u. to 0.990 p.u. 0.980 p.u.
_:19411:112 Trigger P 1:Filter time 2 cycles to 250 cycles 2 cycles
Trigger Q 1
_:19441:1 Trigger Q 1:Mode
•
off
•
on
•
test
off
_:19441:111 Trigger Q 1:Power direc-
tion
•
negative
•
positive
positive
_:19441:101 Trigger Q 1:Max. trigger
active
•
no
•
yes
yes
_:19441:105 Trigger Q 1:Max. trigger 1 A @ 100 Irated 0.20 var to 20000.00 var 120.00 var
5 A @ 100 Irated 0.60 var to 100000.00 var 600.00 var
_:19441:113 Trigger Q 1:Max. trigger
hysteresis
0.900 p.u. to 0.990 p.u. 0.980 p.u.
_:19441:102 Trigger Q 1:Min. trigger
active
•
no
•
yes
yes
_:19441:106 Trigger Q 1:Min. trigger 1 A @ 100 Irated 0.20 var to 20000.00 var 80.00 var
5 A @ 100 Irated 0.60 var to 100000.00 var 400.00 var
_:19441:114 Trigger Q 1:Min. trigger
hysteresis
1.010 p.u. to 1.100 p.u. 1.020 p.u.
_:19441:103 Trigger Q 1:dM/dt rise
active
•
no
•
yes
no
_:19441:107 Trigger Q 1:dM/dt rise (/
Filter time)
1 A @ 100 Irated 0.20 var to 20000.00 var 20.00 var
5 A @ 100 Irated 0.60 var to 100000.00 var 100.00 var
_:19441:115 Trigger Q 1:dM/dt rise
hysteresis
0.900 p.u. to 0.990 p.u. 0.980 p.u.
_:19441:104 Trigger Q 1:dM/dt drop
active
•
no
•
yes
no
_:19441:108 Trigger Q 1:dM/dt drop (/
Filter time)
1 A @ 100 Irated 0.20 var to 20000.00 var 20.00 var
5 A @ 100 Irated 0.60 var to 100000.00 var 100.00 var
_:19441:116 Trigger Q 1:dM/dt drop
hysteresis
0.900 p.u. to 0.990 p.u. 0.980 p.u.
_:19441:112 Trigger Q 1:Filter time 2 cycles to 250 cycles 2 cycles
Fault Recorder
7.4 Trigger Functions 1-Phase
SIPROTEC 5, Fault Recorder, Manual 295
C53000-G5040-C018-5, Edition 11.2017

Siemens SIPROTEC 5 Specifications

General

Series	SIPROTEC 5
Communication Protocols	IEC 61850, DNP3, Modbus
Cybersecurity	Role-based access control, secure communication
Modular Design	Yes
Hardware Redundancy	Optional
Operating Temperature	-25°C to +70°C
Digital Inputs	Configurable, number depends on I/O modules
Digital Outputs	Configurable, number depends on I/O modules
Analog Inputs	Configurable, number depends on I/O modules
Current Transformer Inputs	Configurable, number depends on I/O modules
Voltage Transformer Inputs	Configurable, number depends on I/O modules
Time Synchronization	IRIG-B, SNTP, PTP
Protection Functions	Overcurrent, Differential, Distance, Over/Under Voltage, Frequency
Housing	19-inch Rack Mount
Dimensions	Depends on module configuration
Weight	Depends on module configuration
Voltage Input	24V DC, 48V DC, 110V DC, 125V DC, 220V DC, 250V DC
