Addr. Parameter C Setting Options Default Setting
_:9901:108 Trigger Psum 1:dM/dt
drop (/Filter time)
1 A @ 100 Irated 0.36 Wto 6000.00 W 34.64 W
5 A @ 100 Irated 1.80 W to 300000.00 W 173.21 W
_:9901:116 Trigger Psum 1:dM/dt
drop hysteresis
0.900 p.u. to 0.990 p.u. 0.980 p.u.
_:9901:112 Trigger Psum 1:Filter
time
2cyclesto250 cycles 2 cycles
Trigger Qsum 1
_:9961:1 Trigger Qsum 1:Mode
•
off
•
on
•
test
off
_:9961:111 Trigger Qsum 1:Power
direction
•
negative
•
positive
positive
_:9961:101 Trigger Qsum 1:Max.
trigger active
•
no
•
yes
yes
_:9961:105 Trigger Qsum 1:Max.
trigger
1 A @ 100 Irated 0.36 var to 60000.00 var 207.85 var
5 A @ 100 Irated 1.80 var to 300000.00 var 1039.23 var
_:9961:113 Trigger Qsum 1:Max.
trigger hysteresis
0.900 p.u. to 0.990 p.u. 0.980 p.u.
_:9961:102 Trigger Qsum 1:Min.
trigger active
•
no
•
yes
yes
_:9961:106 Trigger Qsum 1:Min.
trigger
1 A @ 100 Irated 0.36 var to 60000.00 var 138.56 var
5 A @ 100 Irated 1.80 var to 300000.00 var 692.82 var
_:9961:114 Trigger Qsum 1:Min.
trigger hysteresis
1.010 p.u. to 1.100 p.u. 1.020 p.u.
_:9961:103 Trigger Qsum 1:dM/dt
rise active
•
no
•
yes
no
_:9961:107 Trigger Qsum 1:dM/dt
rise (/Filter time)
1 A @ 100 Irated 0.36 var to 60000.00 var 34.64 var
5 A @ 100 Irated 1.80 var to 300000.00 var 173.21 var
_:9961:115 Trigger Qsum 1:dM/dt
rise hysteresis
0.900 p.u. to 0.990 p.u. 0.980 p.u.
_:9961:104 Trigger Qsum 1:dM/dt
drop active
•
no
•
yes
no
_:9961:108 Trigger Qsum 1:dM/dt
drop (/Filter time)
1 A @ 100 Irated 0.36 var to 60000.00 var 34.64 var
5 A @ 100 Irated 1.80 var to 300000.00 var 173.21 var
_:9961:116 Trigger Qsum 1:dM/dt
drop hysteresis
0.900 p.u. to 0.990 p.u. 0.980 p.u.
_:9961:112 Trigger Qsum 1:Filter
time
2cyclesto250 cycles 2 cycles
Trigger Ssum 1
_:10021:1 Trigger Ssum 1:Mode
•
off
•
on
•
test
off
_:10021:101 Trigger Ssum 1:Max.
trigger active
•
no
•
yes
yes
_:10021:105 Trigger Ssum 1:Max.
trigger
1 A @ 100 Irated 0.36 VA to 60000.00 VA 207.85 VA
5 A @ 100 Irated 1.80 VA to 300000.00 VA 1039.23 VA
_:10021:113 Trigger Ssum 1:Max.
trigger hysteresis
0.900 p.u. to 0.990 p.u. 0.980 p.u.
_:10021:102 Trigger Ssum 1:Min.
trigger active
•
no
•
yes
yes
Fault Recorder
7.5 Trigger Functions 3-Phase
SIPROTEC 5, Fault Recorder, Manual 345
C53000-G5040-C018-5, Edition 11.2017
