Addr. Parameter C Setting Options Default Setting
Superv. signal
_:104 Superv.Grp.#:I/O module
ID
•
I/O module 1
•
I/O module 2
•
I/O module 3
•
I/O module 4
•
I/O module 5
•
I/O module 6
•
I/O module 7
•
I/O module 8
•
I/O module 9
•
I/O module 10
•
I/O module 11
•
I/O module 12
•
I/O module 13
•
I/O module 14
•
I/O module 15
I/O module 1
_:105 Superv.Grp.#:Binary
input
1 to 256 1
_:102 Superv.Grp.#:Enable
variable group
•
0
•
1
false
Supervis. grp. start
_:106 Superv.Grp.#:I/O module
ID
•
I/O module 1
•
I/O module 2
•
I/O module 3
•
I/O module 4
•
I/O module 5
•
I/O module 6
•
I/O module 7
•
I/O module 8
•
I/O module 9
•
I/O module 10
•
I/O module 11
•
I/O module 12
•
I/O module 13
•
I/O module 14
•
I/O module 15
I/O module 1
_:107 Superv.Grp.#:Binary
input
1 to 256 1
Supervis. grp. end
_:108 Superv.Grp.#:I/O module
ID
•
I/O module 1
•
I/O module 2
•
I/O module 3
•
I/O module 4
•
I/O module 5
•
I/O module 6
•
I/O module 7
•
I/O module 8
•
I/O module 9
•
I/O module 10
•
I/O module 11
•
I/O module 12
•
I/O module 13
•
I/O module 14
•
I/O module 15
I/O module 1
Supervision Functions
8.3 Supervision of the Secondary System
SIPROTEC 5, Fault Recorder, Manual 371
C53000-G5040-C018-5, Edition 11.2017

Siemens SIPROTEC 5 Specifications

General

Series	SIPROTEC 5
Communication Protocols	IEC 61850, DNP3, Modbus
Cybersecurity	Role-based access control, secure communication
Modular Design	Yes
Hardware Redundancy	Optional
Operating Temperature	-25°C to +70°C
Digital Inputs	Configurable, number depends on I/O modules
Digital Outputs	Configurable, number depends on I/O modules
Analog Inputs	Configurable, number depends on I/O modules
Current Transformer Inputs	Configurable, number depends on I/O modules
Voltage Transformer Inputs	Configurable, number depends on I/O modules
Time Synchronization	IRIG-B, SNTP, PTP
Protection Functions	Overcurrent, Differential, Distance, Over/Under Voltage, Frequency
Housing	19-inch Rack Mount
Dimensions	Depends on module configuration
Weight	Depends on module configuration
Voltage Input	24V DC, 48V DC, 110V DC, 125V DC, 220V DC, 250V DC
