Icon Description
Trigger the pulse of duration T with a positive signal
edge
Trigger the pulse of duration T with a negative signal
edge
SR-Flip-Flop, RS-Flip-Flop, D-Flip-Flop
Characteristic curve
Minimum operate time
Appendix
A.2 Typographic and Symbol Conventions
SIPROTEC 5, Fault Recorder, Manual 457
C53000-G5040-C018-5, Edition 11.2017
