Smartrise C4 User Manual

C4 User Manual
October 25, 2021 ©2021 Smartrise Engineering, Inc. All Rights Reserved Page 63
Menu
Description
Dispatch Offline (1 sec)
Sets the time the car removes itself from the group
after failing to take an assigned call. If either the
dispatch timeout or dispatch offline are set to zero, this
feature is disabled.
XReg Cars
Sets the number of X-Reg cars to include in dispatching
XReg Dest Timeout (10 sec)
Sets the time the XReg car has to respond to a
destination assignment before it temporarily removes
itself from the group and the call is be reassigned. This
prevents excessive delays in answering hall calls due to
someone holding open the car door. If either the
dispatch timeout or dispatch offline are set to zero, this
feature is disabled.
XReg Dest Offline Timeout (10 sec)
Sets the time the XReg car removes itself from the
group after failing to take an assigned call. If either the
dispatch timeout or dispatch offline are set to zero, this
feature is disabled.
Hall Security Mask
Turn ON/OFF which hall board function will have hall
call security.
Hall Security Map Front
Turn ON/OFF Hall Call security for front landings
Hall Security Map Rear
Turn ON/OFF Hall Call security for rear landings
Hall Call Mask
Turn ON/OFF which hall board function the car will
respond to for hall calls
Swing Call Mask
Turn ON/OFF which hall board functions the car will
treat as a swing hall call. NOTE: Swing call mask cannot
overlap with Medical Mask or Hall Call Mask.
Hall Medical Mask
Turn ON/OFF which hall board functions the car will
treat as Emergency Medical Service call. NOTE: Medical
Mask cannot overlap with Swing call mask or Hall Call
Mask.
Hall Rear Door Mask
Turn ON/OFF which hall board functions are for rear
opening. This acts as a modifier to the mask it overlaps
with.
Linked Hall Mask 1
First set of Hall board functions that are turned ON are
linked together. If 01 is ON and 02 is ON, a hall call on
function 1 would latch the lamp for function 2.
Linked Hall Mask 2
Second set of Hall board functions that are turned ON
are linked together. If 01 is ON and 02 is ON, a hall call
on function 1 would latch the lamp for function 2.
Linked Hall Mask 3
Third set of Hall board functions that are turned ON are
linked together. If 01 is ON and 02 is ON, a hall call on
function 1 would latch the lamp for function 2.
Linked Hall Mask 4
Fourth set of Hall board functions that are turned ON
are linked together. If 01 is ON and 02 is ON, a hall call
on function 1 would latch the lamp for function 2.
