C4 User Manual
Page 158 ©2021 Smartrise Engineering, Inc. All Rights Reserved October 25, 2021
14.8 Floor Openings
The front opening mask marks the landings that have front openings and are located under
address 32-0000 – 32-0002. The rear opening mask marks the landings that have rear openings
and are located under addresses 32-0004 – 32-0006. For the list of parameters, see the C4
Parameter List
The following procedure describes how to set the floor the front door opens.
1. Navigate to MAIN MENU | SETUP | FLOORS. See Figure 56.
2. From the FLOOR menu, scroll and select Openings (Front or Rear).
Figure 246: FLOOR Menu – Openings
3. From the FLOOR OPENING (Front or Rear) menu, scroll and select the floors the front
and/or rear door is going to open.
Figure 247: FLOOR OPENING Menu
4. Scroll right and press Save.
14.9 Store Floor Level
The store floor level stores the position of the floor level.
The following procedure describes how to store the car’s current position as the position of the
selected floor.
1. Navigate to MAIN MENU | SETUP | FLOORS. See Figure 56.
2. From the FLOORS menu, scroll and select Store Floor Level.
Figure 248: FLOORS Menu – Store Floor Level
