C4 User Manual
Page 244 ©2021 Smartrise Engineering, Inc. All Rights Reserved October 25, 2021
29.9 Enable Old FRAM
The MR board is configured to work with old ferroelectric random access memory (FRAM)
hardware.
The following procedure describes how to enable the MR board to work with old FRAM.
1. Navigate to MAIN MENU | SETUP | MISCELLANEOUS. See Figure 58.
2. From the MISCELLANEOUS menu, scroll and select Enable Old FRAM.
Figure 430: MISCELLANEOUS Menu – Enable Old FRAM
3. From the ENABLE OLD FRAM menu, scroll and select On to enable the MR to work with
old FRAM.
Figure 431: ENABLE OLD FRAM Menu
4. Scroll right and press Save.
29.10 Enable Pit Inspection
Enables the Pit inspection operation on the controller. Input 501 on the MR board must be used
to toggle inspection operation ON/OFF. Dip 4B must also be enabled to use the operation.
The following procedure describes how to enable pit inspection.
1. Navigate to MAIN MENU | SETUP | MISCELLANEOUS. See Figure 58.
To Next Page
