C4 User Manual
Page 58 ©2021 Smartrise Engineering, Inc. All Rights Reserved October 25, 2021
The table below lists the Setup – Miscellaneous and NTS menu structures.
Table 22: Setup – Miscellaneous and NTS Menu Structures
Menu
Description
Setup
Miscellaneous
Miscellaneous menu options
NTS
Normal Terminal Slowdown menu option
Miscellaneous
ByPass Term Limit
Bypasses terminal limit faults. This option is automatically
turned off when in automatic operation.
Enable Const. Box
Enable/Disable Construction Box. When enabled, onboard
inspection buttons are ignored on construction operation
and onboard inputs are used.
Max Run Time
Sets the max run time allowed in automatic operation
before the car faults (F116). If set to zero, this fault is
suppressed.
CT. Insp. Req. IC
Requires In-Car inspection to enable CT inspection
Dis. IdleTrvArrow
When set ON, CE travel arrows reflect the motion
direction of the car. When set OFF, the arrows reflect the
motion direction of the car and the arrival direction after
a run.
En. UI Drive Edit
Enables editing of drive parameters from the MR board UI
or the GUI
Enable Latches CC
When set ON, car call security enable input latches a car
call
Fan & Light Timer
Sets the time the car may be idle before its fan and light
output is turned off. If a longer timer is needed, the
extended fan and light timer should be used instead.
Units are in seconds.
Ext. Fan Timer
Extended fan and light timer
Car to Lobby Flr
Sets the floor the car moves to when the car to lobby
input is activated. This value is zero based.
Arrival Update Time
Sets the time before arriving at a floor to update arrival
lantern outputs. If set to zero, arrival outputs updates
when doors begin to open. Units are in seconds.
Enable Old FRAM
When set ON, the MR board is configured to work with
old FRAM hardware
Enable Hall Security
Enables hall call security
Enable Pit Inspection
Enables pit inspection
Enable Landing Inspection
Enables landing inspection
Parking
Parking options
OOS
Car out of service options
En. 3 Digit PI
Enables 3-digit PI
Payment Passcode
Controller passcode
