C4 User Manual
October 25, 2021 ©2021 Smartrise Engineering, Inc. All Rights Reserved Page 221
Input
Description
TCL
Indicates that the manual hall doors for the top floor
rear opening are closed.
Table 40: Description of Emergency Power Inputs
Input
Description
AutoSelect
After all cars have completed their recall, a
preconfigured number of cars are released to go back
to automatic operation. These cars are auto selected.
EP On
Car is on generator power. Puts car on emergency
power operation.
Pretransfer
Car is moving from generator Description back to main
line power. Cars should stop at their nearest reachable
landings and hold doors open.
Select1
After all cars have completed their recall, a
preconfigured number of cars are released to go back
in to automatic operation. These cars are manually
selected via the select inputs if Auto Select is inactive.
Select2
After all cars have completed their recall, a
preconfigured number of cars are released to go back
in to automatic operation. These cars are manually
selected via the select inputs if Auto Select is inactive.
Select3
After all cars have completed their recall, a
preconfigured number of cars are released to go back
in to automatic operation. These cars are manually
selected via the select inputs if Auto Select is inactive.
Select4
After all cars have completed their recall, a
preconfigured number of cars are released to go back
in to automatic operation. These cars are manually
selected via the select inputs if Auto Select is inactive.
Select5
After all cars have completed their recall, a
preconfigured number of cars are released to go back
in to automatic operation. These cars are manually
selected via the select inputs if Auto Select is inactive.
Select6
After all cars have completed their recall, a
preconfigured number of cars are released to go back
in to automatic operation. These cars are manually
selected via the select inputs if Auto Select is inactive.
Select7
After all cars have completed their recall, a
preconfigured number of cars are released to go back
in to automatic operation. These cars are manually
selected via the select inputs if Auto Select is inactive.
Select8
After all cars have completed their recall, a
preconfigured number of cars are released to go back
in to automatic operation. These cars are manually
selected via the select inputs if Auto Select is inactive.
