C4 User Manual
October 25, 2021 ©2021 Smartrise Engineering, Inc. All Rights Reserved Page 23
DIP Switch
Functionality
Description
DIP 4
N/A
N/A
DIP 5
N/A
N/A
DIP 6
N/A
N/A
DIP 7
Pop-up Blocker
Disables the fault pop-up messages.
Faults can still be viewed in the
active and logged faults.
DIP 8
N/A
N/A
The table below lists the functionality configuration for the SRU board SR3030 Bank B DIP
switch settings.
Table 5: SRU Board SR3030 Bank B DIP Switch Setting Configuration
DIP Switch
Functionality
Description
DIP 1
COP (Not CT)
Must be turned on for COP
operation and off for CT operation.
DIP 2
Enable Rear Doors
Must be set if rear doors are
present.
DIP 3
Enable Landing Insp
Must be set when conducting
landing maintenance.
DIP 4
Enable Pit Insp
Must be set when conducting pit
maintenance.
DIP 5
N/A
N/A
DIP 6
N/A
N/A
DIP 7
N/A
N/A
DIP 8
N/A
N/A
2.3 I/O Board/Riser Board SR3031
The SR3031 Board serves two purposes:
1. Designated as a Riser board (DIP 8 is ON) for fire service or emergency power
connections and hall network connections.
• Additional Riser boards are added by increasing the addressing by one, for example,
Riser board 2 has DIP 8 and DIP 1 ON. Up to four Riser boards can be used within the
system.
2. Designated as an Expansion board (DIP 8 is OFF) to provide 24 VDC inputs and outputs
that can be programmed as required.
• Expansion boards are broken up into groups of 8. Up to 40 Expansion boards can be
used within the system.
