33.3.1 Main Recall
The main recall is where the car is recalled to a main recall floor during a fire.
33.3.1.1 Main Recall Floor
The following procedure describes how to set the designated landing.
1. Navigate to MAIN MENU | SETUP | FIRE. See Figure 57.
2. From the FIRE SERVICE menu, scroll and select Main Recall.
Figure 546: FIRE SERVICE Menu – Main Recall
3. From the MAIN RECALL menu, scroll and select Floor.
Figure 547: MAIN RECALL Menu – Floor
4. From the MAIN RECALL FLOOR menu, enter the recall floor.
Figure 548: MAIN RECALL FLOOR Menu
5. Scroll right and press Save.
33.3.1.2 Main Recall Door
The following procedure describes how to set which door opens during a fire.
1. Navigate to MAIN MENU | SETUP | FIRE. See Figure 57.
2. From the FIRE SERVICE menu, scroll and select Main Recall. See Figure 546.
