C4 User Manual
Page 8 ©2021 Smartrise Engineering, Inc. All Rights Reserved October 25, 2021
There are two sets of DIP switch settings for the MR Board:
• Bank A (upper one)
• Bank B (lower one)
Each setting is configured for a different functionality.
The table below lists the functionality and configuration for the Bank A DIP switch setting.
Table 1: MR Board SR3032 Bank A DIP Switch Setting Configuration
DIP Switch
Functionality
Description
DIP 1
CPU Stop Switch
Halts parameters updates and used
to reset fire and latched faults .
DIP 2
N/A
N/A
DIP 3
Capture Car/Disable Doors
Takes the car out of the group and
completes all car calls before
disabling the doors.
Bypasses EMS operation.
DIP 4
Enable GUI Edit (v1.02.54 and above)
Allows parameter edits from
external GUI.
DIP 5
Learn Mode
Activates learn mode on the
controller to learn the hoistway.
DIP 6
Enable Tune
Sends message to the drive to begin
the tune process. Used after setting
the drive in motor tune or encoder
learn.
DIP 7
Pop-up Blocker
Disables the fault pop-up messages.
Faults can still be viewed in the
active and logged faults.
DIP 8
Bootloader Flag
Sets all boards in Bootloader mode
to update software.
The table below lists the functionality configuration for the MR Board SR3032 Bank B dip switch
setting.
Table 2: MR Board SR3032 Bank B DIP Switch Setting Configuration
DIP Switch
Functionality
Description
DIP 1
Invert NTS Output
When set to ON, NTS output is
Active Low.
DIP 2
Rear Doors
Must be set if rear doors are
present.
DIP 3
Enable Landing Insp
Must be set if landing inspection
operation is used.
DIP 4
Enable Pit Insp
Must be set if Pit inspection
operation is used.
