Smartrise C4 User Manual

C4 User Manual
Page 66 ©2021 Smartrise Engineering, Inc. All Rights Reserved October 25, 2021
Menu
Description
Timer Enable Only
When set ON, Sabbath operation is activated by only
the configured Sabbath Start Time and Sabbath End
Time
Key or Timer Enable
When set ON, Sabbath operation is activated by either
keyswitch input or configured Sabbath Start Time and
Sabbath End Time
Friday Start Time
Sets the Friday start time for Sabbath when timer
enable is set. Format is HHMM, for example 12:34 PM
would be 1234.
Saturday End Time
Sets the Saturday end time for Sabbath when timer
enable is set. Format is HHMM, for example, 12:34 PM
would be 1234.
Door Dwell Timer (1 sec)
Sets the time car doors remain open while in Sabbath
operation
Sabbath (F)
Sets the front opening floors to be serviced during
Sabbath operation
Sabbath (R)
Sets the rear opening floors to be serviced during
Sabbath operation
Destinations Up
Set which floors to stop at during Sabbath up operation
Destinations Down
Set which floors to stop at during Sabbath down
operation
Swing
Calls Enable Swing
Allows swing calls to activate swing operation
Stay in Group
Allows the car to continue to take regular hall calls
while in swing operation
Idle Timer (1 sec)
If Swing mode is entered by a button press, this timer
specifies how long to remain in Swing operation once
the car is idle
Attendant
Dispatch Timeout
Sets the time the car removes itself from answering hall
calls after failing to take an assigned call while on
attendant service. If either the dispatch timeout or
dispatch offline are set to zero, this feature is disabled.
If only one car is on attendant service, this feature
should be disabled.
Buzzer Time (100ms)
Specifies how long to sound the buzzer to alert the
attendant that a hall call was pressed
