Smartrise C4 User Manual

C4 User Manual
Page 224 ©2021 Smartrise Engineering, Inc. All Rights Reserved October 25, 2021
Output
Description
Buzzer
Triggers an audible in car buzzer when the car is
overloaded, on fire, nudging, on EMS Phase 1, or when
on Attendant and there is a demand.
Car To Lobby
Activates if the car has finished its recall.
CC Acknowledge
Activates when a car call is placed. This is used in
Canada for blind people.
Chime
Activates when the car is in an automatic mode of
operation and the passing chime disable Output is
inactive. The chime is triggered for 500ms every time
the car's PI changes.
Decelerating
Activates when the car is in the deceleration stage of
its run.
Distress Buzzer
At a central control console, a distress and light buzzer
will be provided for each elevator and an acknowledge
button common to all elevators. Pressing the distress
alarm button, triggering the emergency stop switch, if
a dispatched car remains at a landing for >30 seconds,
or if the electrical safety circuit is open will turn on the
distress light, and pulse the distress buzzer. The
Distress light will remain lit until the acknowledge
button is pressed.
Distress Lamp
At a central control console, a distress and light buzzer
will be provided for each elevator and an acknowledge
button common to all elevators. Pressing the distress
alarm button, triggering the emergency stop switch, if
a dispatched car remains at a landing for >30 seconds,
or if the electrical safety circuit is open will turn on the
distress light, and pulse the distress buzzer. The
Distress light will remain lit until the acknowledge
button is pressed.
In Service
Activates if hall calls are not disabled and the car is not
faulted.
In Use
Activates when the car is not in normal operation, is in
motion, or has its doors open.
Group Redundancy
Switches power to a redundant set of Riser boards.
Lamp At Recall
Activates when the car has completed EMS, Fire, or
emergency power recall.
Lamp Attd Above
Activates when the car is in attendant operation and
there is a hall call at a floor above.
Lamp Attd Below
Activates when the car is in attendant operation and
there is a hall call at a floor below.
Lamp EMS
Activates when the car is in EMS Phase 1 or Phase 2.
Lamp Indp Srv
Activates when the car is in independent service
operation.
