Smartrise C4 User Manual

C4 User Manual
October 25, 2021 ©2021 Smartrise Engineering, Inc. All Rights Reserved Page 319
Fault Number
Fault Name
Description
16
BFL LOSS
MR BFL input lost.
17
CT SW LOSS
CT Switch input (SF1) lost.
18
ESC HATCH LOSS
CT Escape Hatch input (SF2) lost.
19
CAR SAFE LOSS
CT Car Safeties input (SF3) lost.
20
IC STOP SW
COP IC Stop input (SF2) lost.
21
FIRE STOP SW
COP Fire Stop Switch input (SF3) lost.
22
INSP
MR board will not fault. It will either refuse
to run and issue an alarm, or the car mode
will be Invalid Insp.
23
ACCESS
Attempt to move on hoistway access
inspection is invalid combination of locks
open and access switches, or multiple
access switches are active at the same
time.
24
LFT
Lock input lost, door zone input lost, and
locks are not bypassed due to hoistway
access or Hall Bypass switch.
25
LFM
Lock input lost, door zone input lost, and
locks are not bypassed due to hoistway
access or Hall Bypass switch.
26
LFB
Lock input lost, door zone input lost, and
locks are not bypassed due to hoistway
access or Hall Bypass switch.
27
LRT
Lock input lost, door zone input lost, and
locks are not bypassed due to hoistway
access or Hall Bypass switch.
28
LRM
Lock input lost, door zone input lost, and
locks are not bypassed due to hoistway
access or Hall Bypass switch.
29
LRB
Lock input lost, door zone input lost, and
locks are not bypassed due to hoistway
access or Hall Bypass switch.
30
GSWF
Gate switch input lost, door zone input
lost, and car doors are not bypassed due to
hoistway access or Car Door Bypass switch.
31
GSWR
Gate switch input lost, door zone input
lost, and car doors are not bypassed due to
hoistway access or Car Door Bypass switch.
32
PF PIT INSP
Preflight failed for the MR 501 (Pit
Inspection) input.
33
PF LND INSP
Preflight failed for the MR 502 (Landing
Inspection) input.
34
PF BFL
Preflight failed for MR BFL input.
35
PF TFL
Preflight failed for MR TFL input.
