Smartrise C4 User Manual

C4 User Manual
October 25, 2021 ©2021 Smartrise Engineering, Inc. All Rights Reserved Page 51
Menu
Description
Hold Voltage
Set secondary brake hold voltage
Relevel Voltage
Set the releveling voltage of the secondary brake. This
voltage should be set to where the brake barely lifts
during releveling to allow the sheave to turn under the
brake.
Pick Time
Amount of time pick voltage is maintained before
switching to hold voltage
Ramp Time
Amount of time the brake scales to full pick voltage on
automatic operation
Ramp Time – Relevel
Amount of time the brake scales to full releveling voltage
BPS – NC
Brake Pick switch is normally closed
BPS – Stuck Active
Disables secondary BPS stuck picked check
BPS – Stuck Inactive
Disables secondary BPS stuck dropped check
BPS – Timeout
Sets the timeout for secondary BPS stuck active and stuck
inactive faults (F189/F190) to be asserted. Minimum of
three seconds.
Floors
Number Of Floors
Allows for setting the number of floors within the
building
Too High/ Too Low
Used to adjust the learned position of the floor when
setting floor levels
Enable Releveling
Enables releveling operation
Relevel Zone Size (.02”)
Sets the size of the releveling zone (dead zone)
Relevel Delay
The time the controller waits before engaging a Relevel
command while in a door zone and outside the dead
zone
Openings (F)
Allows for setting the floors the front door opens
Openings (R)
Allows for setting the floors the rear door opens
Security (F)
Allows for setting the security parameters for front door
Security (R)
Allows for setting the security parameters for rear door
Store Floor Level
Sets the position of the short floor level
Short Floor Opening
Sets overlapping door zones (short floors)
Timed CC Security
Allows for setting car call security for specific times
Timed HC Security
Allows for setting hall call security for specific times
Time CC Security
Enable Floor (F)
Allows for enabling timed security for front openings
Enable Floor (R)
Allows for enabling timed security for rear openings
Start (M-F)
Sets the time that floor access is denied during M-F
Stop (M-F)
Sets the time that floor access is resumed on M-F
Start (S-S)
Sets the time that floor access is denied during S-S
Stop (S-S)
Sets the time that floor access is resumed on S-S
