C
ONFIGURING
THE
S
WITCH
2-80
CLI - This example sets the rate limit level for input and output traffic
passing through port 3 and 4.
Showing Port Statistics
You can display standard statistics on network traffic from the Interfaces
Group and Ethernet-like MIBs, as well as a detailed breakdown of traffic
based on the RMON MIB. Interfaces and Ethernet-like statistics display
errors on the traffic passing through each port. This information can be
used to identify potential problems with the switch (such as a faulty port or
unusually heavy loading). RMON statistics provide access to a broad range
of statistics, including a total count of different frame types and sizes
passing through each port. All values displayed have been accumulated
since the last system reboot, and are shown as counts per second. Statistics
are refreshed every 60 seconds by default.
Note: RMON groups 2, 3 and 9 can only be accessed using SNMP
management software.
Statistical Values
Console(config)#interface ethernet 1/3 3-85
Console(config-if)#rate-limit input level 3 3-151
Console(config-if)#rate-limit output level 3 3-151
Console(config-if)#exit
Console(config)#interface ethernet 1/4
Console(config-if)#rate-limit input level 6
Console(config-if)#rate-limit output level 6
Console(config-if)#
Parameter Description
Interface Statistics
Received Octets The total number of octets received on the interface,
including framing characters.
Received Unicast
Packets
The number of subnetwork-unicast packets delivered to
a higher-layer protocol.
Received Multicast
Packets
The number of packets, delivered by this sub-layer to a
higher (sub-)layer, which were addressed to a multicast
address at this sub-layer.
