C
ONFIGURING
THE
S
WITCH
2-4
You are allowed three attempts to enter the correct password; on the third
failed attempt the current connection is terminated.
Configuration Options
Configurable parameters have a dialog box or a drop-down list. Once a
configuration change has been made on a page, be sure to click on the
Apply button to confirm the new setting. The following table summarizes
the Web page configuration buttons.
Panel Display
The Web agent displays an image of the switch’s ports, indicating whether
each link is up or down. Clicking on the image of a port opens the Port
Configuration page as described on page 2-67.
Button Action
Apply Sets specified values to the system.
Revert Cancels specified values and restores current values
prior to pressing Apply.
Help Links directly to webhelp.
To Next Page
