A
DDRESS
T
ABLE
S
ETTINGS
2-89
For example, the following screen shows the dynamic addresses for
port 21.
CLI – This example also displays the address table entries for port 11.
Changing the Aging Time
You can change the aging time for entries in the dynamic address table.
Command Attributes
Aging Time – The time after which a learned entry is discarded.
(Range: 10-30000 seconds; Default: 300 seconds)
Web – Click Address Table, Address Aging. Specify the new aging time,
then click Apply.
Console#show mac-address-table ethernet 1/11 3-101
Interface Mac Address Vlan Type
--------- ----------------- ---- -----------------
Eth 1/11 00-10-b5-62-03-74 1 Learned
Console#
