C
OMMAND
L
INE
I
NTERFACE
3-192
Example
The following example shows how to assign WRR weights of 1, 4, 16 and
24 to the CoS priority queues 0, 1, 2 and 3:
Related Commands
show queue bandwidth (3-195)
queue cos-map
Use this command to assign class of service (CoS) values to the egress
queues (i.e., hardware output queues 0 - 3). Use the no form to set the
CoS map to the default values.
Syntax
queue cos-map queue_id [cos1 ... cosn]
no queue cos-map
• queue_id - The ID of the priority queue.
Range is 0 to 3, where 3 is the highest priority queue.
• cos1 .. cosn - The CoS values that are mapped to the queue ID. It is a
space-separated list of numbers. The CoS value is a number from 0
to 7, where 7 is the highest priority.
Console(config)#queue bandwidth 1 4 16 24
Console(config)#
