C
ONFIGURING
THE
S
WITCH
2-56
Web – Select Security, 802.1X, Statistics. Select the required port and then
click Query. Click Refresh to update the statistics.
CLI – This example displays the dot1x statistics for port 2.
Access Control Lists
Access Control Lists (ACL) provide packet filtering for IP frames (based
on address, protocol, TCP/UDP port number or TCP control code) or
any frames (based on MAC address or Ethernet type). To filter incoming
packets, first create an access list, add the required rules, and then bind the
list to a specific port.
Console#show dot1x statistics 3-168
Eth 1/2
Rx: EXPOL EAPOL EAPOL EAPOL EAP EAP EAP
Start Logoff Invalid Total Resp/Id Resp/Oth LenError
0 0 0 0 0 0 0
Last Last
EAPOLVer EAPOLSrc
0 30-30-30-30-30-30
Tx: EAPOL EAP EAP
Total Req/Id Req/Oth
29 21 0
Console#
