L
INK
A
GGREGATION
C
OMMANDS
3-149
Example
The following example creates trunk 1 and then adds port 11:
lacp
Use this command to enable 802.3ad Link Aggregation Control Protocol
(LACP) for the current interface. Use the no form to disable it.
Syntax
lacp
no lacp
Default Setting
Disabled
Command Mode
Interface Configuration (Ethernet)
Command Usage
• The ports on both ends of an LACP trunk must be configured for full
duplex, either by forced mode or auto-negotiation.
• A trunk formed with another switch using LACP will automatically be
assigned the next available port-channel ID.
• If the target switch has also enabled LACP on the connected ports, the
trunk will be activated automatically.
• If more than four ports attached to the same target switch have LACP
enabled, the additional ports will be placed in standby mode, and will
only be enabled if one of the active links fails.
Console(config)#interface port-channel 1
Console(config-if)#exit
Console(config)#interface ethernet 1/11
Console(config-if)#channel-group 1
Console(config-if)#
