C
ONFIGURING
THE
S
WITCH
2-128
Web – Click VLAN, Private VLAN, Port Information or Trunk
Information.
CLI – This example shows the switch configured with primary VLAN 5
and secondary VLAN 6. Port 3 has been configured as a promiscuous port
and mapped to VLAN 5, while ports 4 and 5 have been configured as host
ports and associated with VLAN 6. This means that traffic for port 4 and 5
can only pass through port 3.
Configuring Private VLAN Interfaces
Use the Private VLAN Port Configuration and Private VLAN Trunk
Configuration menus to set the private VLAN interface type, and associate
the interfaces with a private VLAN.
Console#show vlan private-vlan 3-137
Primary Secondary Type Interfaces
-------- ----------- ---------- ------------------------------
5 primary Eth1/ 3
5 6 community Eth1/ 4 Eth1/ 5
Console#
