P RIVATE VLAN S
2-127
CLI – This example associates community VLANs 6 and 7 with primary
VLAN 5.
Displaying Private VLAN Interface Information
Use the VLAN Port Information and VLAN Trunk Information menus to
display the interfaces associated with private VLANs.
Command Attributes
• Port/Trunk – The switch interface.
• PVLAN Port Type – Displays private VLAN port types.
- Normal – The port is not configured in a private VLAN.
- Host – The port is a community port and can only communicate
with other ports in its own community VLAN, and with the
designated promiscuous port(s).
- Promiscuous – A promiscuous port can communicate with all the
interfaces within a private VLAN.
• Primary VLAN – Conveys traffic between promiscuous ports, and
between promiscuous ports and community ports within the
associated secondary VLANs.
• Community VLAN – A community VLAN conveys traffic between
community ports, and from community ports to their designated
promiscuous ports.
• Isolated VLAN – Conveys traffic only between the VLAN’s isolated
ports and promiscuous ports. Traffic between isolated ports within the
VLAN is blocked.
• Trunk – The trunk identifier. (Port Information only.)
Console(config)#vlan database 3-121
Console(config-vlan)#private-vlan 5 association 6 3-133
Console(config-vlan)#private-vlan 5 association 7
Console(config)#
