SMC Networks 6724AL2 User Manual

C OMMAND L INE I NTERFACE
3-166
Example
dot1x re-authentication
Enables periodic re-authentication globally for all ports. Use the no form
to disable re-authentication.
Syntax
dot1x re-authentication
no dot1x re-authentication
Command Mode
Global Configuration
Example
dot1x timeout quiet-period
Sets the time that a switch port waits after the Max Request Count has
been exceeded before attempting to acquire a new client. Use the no form
of this command to reset the default.
Syntax
dot1x timeout quiet-period seconds
no dot1x timeout quiet-period seconds
seconds - The number of seconds. (Range: 1-65535)
Default
60 seconds
Command Mode
Global Configuration
Console#dot1x re-authenticate
Console#
Console(config)#dot1x re-authentication
Console(config)#
