C ONFIGURING 802.1 X P ORT A UTHENTICATION
2-55
Displaying 802.1x Statistics
This switch can display statistics for dot1x protocol exchanges for any
port.
Statistical Values
Parameter Description
Rx EXPOL Start The number of EAPOL Start frames that have been
received by this Authenticator.
Rx EAPOL Logoff The number of EAPOL Logoff frames that have been
received by this Authenticator.
Rx EAPOL Invalid The number of EAPOL frames that have been received
by this Authenticator in which the frame type is not
recognized.
Rx EAPOL Total The number of valid EAPOL frames of any type that
have been received by this Authenticator.
Rx EAP Resp/Id The number of EAP Resp/Id frames that have been
received by this Authenticator.
Rx EAP Resp/Oth The number of valid EAP Response frames (other than
Resp/Id frames) that have been received by this
Authenticator.
Rx EAP LenError The number of EAPOL frames that have been received
by this Authenticator in which the Packet Body Length
field is invalid.
Rx Last EAPOLVer The protocol version number carried in the most
recently received EAPOL frame.
Rx Last EAPOLSrc The source MAC address carried in the most recently
received EAPOL frame.
Tx EAPOL Total The number of EAPOL frames of any type that have
been transmitted by this Authenticator.
Tx EAP Req/Id The number of EAP Req/Id frames that have been
transmitted by this Authenticator.
Tx EAP Req/Oth The number of EAP Request frames (other than Rq/Id
frames) that have been transmitted by this
Authenticator.
